IC Series Charger Interface
14
LEGEND
Solid blue - AC power available
Flashing amber - External error
condition - caution see display
panel details
Solid red - Charge fault see
display panel details
Flashing green - USB port active
Solid green - Safe to remove USB
flash drive
Flashing green - Low state of
charge
Solid green - High state of
charge
Flashing green - High state of
charge
Solid green - Charge complete
