IC Series Charger Interface
20
CONFIGURING THE IC650
CHARGER USING A USB
FLASH DRIVE
Using the Delta-Q software, USB storage
drives can be pre-programmed to certain
charger configurations. To use the USB port,
follow these steps:
1. Insert the USB flash drive at any time,
but preferably not during a charge cycle.
Stop the charge cycle by removing AC
power or the DC connection to the
batteries. The charger can power the
USB port from the AC connection (DC
disconnected) or from the DC connection
(AC disconnected).
2.
If there is enough disk space (about 2 MB),
the charger will write charge tracking
data to the drive. The Fault/Error/USB
Indicator will flash green during reading
and writing.
3.
If the drive contains compatible
configuration files, the charger will load
them.
4. The charger will briefly reset.
5.
Remove the drive when the Fault/Error/
USB indicator is solid green. Add note:
