Delta-q IC SERIES Installation & Troubleshooting Guide

ELECTRICAL INSTALATION
23
IC650 COMM Model Rear Panel
IC900 COMM Model Rear Panel
IC1200 COMM Model Rear Panel
AC
Input
AC
Input
AC
Input
DC
Output
Block
DC
Output
Block
DC
Output
Block
Signals and Control
Signals and Control
Signals and Control
The charger has either two or three
connectors on the rear panel depending
on the model. The COMM model with all
connectors is shown below. The BASE
model does not have a Signals & Control
Connector.

Delta-q IC SERIES Specifications

General

Brand	Delta-q
Model	IC SERIES
Category	Battery Charger
Language	English
