Delta-q IC SERIES - IC650 DC Output

IC650 DC Output
29
Warning: Be careful not to allow battery
voltage to be applied to the blade terminals
(C1, C2, C3), as it will result in permanent
damage to the charger.
B-
C1 C3 B+
C2
