Delta-q IC SERIES Installation & Troubleshooting Guide

iC900/1200 DC Output
33
PIN
RECOMMENDED
WIRE SIZE
AWG/MM2
DESC.
B-
12 /4.0
(IC900)
10 /6.0
(IC1200-24V)
12 /2.5
(IC1200-36V, 48V
Battery Negative
B+ Battery Positive
L1
22/0.5
(2-conductor
cable)
Remote LED red anode/
green cathode
L2
Remote LED green anode/
red cathode
C1
18/1.0
(2-conductor
cable)
Battery temperature sense
negative
C2
Battery temperature sense
positive
C3 12/4.0 Interlock Signal
F+
N/A
Fan power/control;
0-12 VDC (IC1200 only)
F-
Fan power/control return;
0-12 VDC (IC1200 only)
Table 2-1
