Delta-q IC SERIES Installation & Troubleshooting Guide

Signals & Control Connector
46
WIRE COLOR PIN DESC.
WHITE / BLACK 1 CAN GND
BLUE 2 Interlock-NC
PURPLE 3 Interlock-Common
PINK 4 Interlock-NO
WHITE / RED 5
Battery temperature
sense +ve
ORANGE 6 CAN High
BLACK 7 Signal Ground
BROWN 8 Not used
YELLOW 9
IC650: unused
IC900/IC1200: APO
WHITE / ORANGE 10 CAN Low
GREY 11 Not used
GREEN 12 Remote LED Green +ve
RED 13 Remote LED Red +ve
WHITE 14
Battery temperature
sense -ve
Table 3-1
