Delta-q QUIQ Series User Manual

WIRE
COLOR
TERMINATION DESC. WIRE SIZE
Red
3/8” Ring
Terminal
Battery
Positive
12AWG/
3.3mm2
Black
3/8” Ring
Terminal via
Thermistor Block
Battery
Negative
12AWG/
3.3mm2
White
Overmoulded
Thermistor Block
Temperature
Sensor
Signal
12AWG/
3.3mm2
Green
Female ¼”
Spade Terminal
(ships shrouded)
Standard
Interlock
12AWG/
3.3mm2
Table 3-1
Electrical Installation
31

Delta-q QUIQ Series Specifications

General

Input Voltage	85-265 VAC
IP Rating	IP66
Input Frequency	45-65 Hz
Storage Temperature	-40°C to +85°C
Cooling Method	Natural Convection
Operating Temperature	-20°C to 50°C
Protection	Overtemperature
Agency Approvals	UL, CE
Communication	CAN bus
