Delta-q QUIQ Series - Page 35

CONN
PIN
WIRE DIAMETER
AWG
DESC.
1 14-20 Temp Sense+
2 14-20 Temp Sense-
3 14-20 Signal Interlock NC
4 14-20 Signal Interlock COM
5 14-20 Signal Interlock NO
6 14-20 LED +
7 14-20 LED -
8 NOT USED
Pin Configuration for Signal
Connector (Deutsch DT05-08SA)
Table 4-1
Electrical Installation
35
