Delta-q QUIQ Series User Manual

CONN
PIN
NOTES
1
Connect to NTC 10k 5% Thermistor.
IMPORTANT: If using a temperature-sensing
algorithm, connect to Battery Negative or
Temp Sense Negative if not installed.
CAUTION: Ensure B+ and B- polarity are
correct before connecting this pin otherwise
this input may be damaged.
2 Internally connected to battery negative
3 Normally Closed
4
Common, 1A maximum. Inline 1A fuse
installation recommended.
5 Normally Open
6 Red Cathode, 4.5 mA
7 Green Cathode, 4.5 mA
8 Install sealing plug 114017
Pin Configuration for Signal
Connector (Deutsch DT05-08SA)
Table 4-2
Electrical Installation
36

Delta-q QUIQ Series Specifications

General

Input Voltage	85-265 VAC
IP Rating	IP66
Input Frequency	45-65 Hz
Storage Temperature	-40°C to +85°C
Cooling Method	Natural Convection
Operating Temperature	-20°C to 50°C
Protection	Overtemperature
Agency Approvals	UL, CE
Communication	CAN bus
