9
UNPACKING
Remove any protective materials and coatings from all of the parts and the tool. The protective coatings can be removed by spraying
WD-40 on them and wiping it o with a soft cloth. This may need redone several times before all of the protective coatings are
removed completely.
If any parts are missing, do not attempt to plug in the power cord and turn “ON” the machine. The machine should
only be turned “ON” after all the parts have been obtained and installed correctly.
M6 x 16mm carriage bolts (2)
M6 Lock washers (2)
M6 Flat washers (4)
Eye shield locking knobs (2)
HP1
HP1 HP2 HP3
HP5
HP6
HP7
HP2
HP3
HP4
HP6
HP5
HP7
HARDWARE PACKAGE
Tool rest locking knob (2)
M5 x 10mm Inner hex head screw with
M5 Flat Washer and M5 Lock Washer (4)
4mm Hex Wrench (1)
002862
002834
002841 002860
002833
002845
002839
HP4
