2-3 Annotation and symbol
The two signs shown on the manual indicating important instruction need to be followed.
Read before Operation Maybe Dangerous/Follow Instructions
PROTECTIVE GROUNDING TERMINAL: A terminal which must be
connected to earth ground prior to making any other connection to the
equipment.
This symbol indicates the word “phase”.
This symbol indicates the principal on/off switch is in the “ON” position.
This symbol indicates the principal on/off switch is in the “STANDBY”
position.
2-4 FRONT PANEL
Fig 2-1.1 Front Panel for 700VA or 1KVA
!
Operation panel
