Delta AC MAX User Manual

v1.0.0
34
7 Specifications
Version
Smart
Charging mode
Mode 3
Charging interface
IEC 62196-2: Type 1 plug, Type 2 plug, Type 2 socket, or Type 2
socket with shutter
Input/output rating
220-240 Vac, single phase, 16A or 32 A max., 50-60 Hz
380-415 Vac, three phase, 16A or 32 A max., 50-60 Hz
Input wiring
Single phase: L1, N, PE
Three phase: L1, L2, L3, N, PE/ L1, L2, L3, PE (IT)
Standby power
< 5 W*
Altitude
2000m
Internal residual current detection
AC 30mA, DC 6mA
Surge protection
Class II
Electrical protection
Over current protection, short circuit protection, over voltage
protection, under voltage protection, ground fault protection, surge
protection, over temperature protection
Cold load pick-up
Randomized delay between 5 and 100 seconds before the charge
resume after power outages.
Status indicators
Blue, green, red, yellow
Network interface
Bluetooth, Ethernet, wifi or cellular
Charging protocol
OCPP 1.6J
Card reader
RFID card reader compliant to ISO/IEC 14443 A/B
Operating temperature
-30 ℃ to +50 ℃ ( -22 ℉ to +122 ℉)
Storage temperature
-40 ℃ to +80 ℃ (-40 ℉ to +176 ℉)
Relative humidity
< 95%, non-condensing
Length of charging cable
5 m, straight cable
Ingress protection
IP55
Impact protection
IK09
Cooling
Natural cooling
Dimension (H x W x D)
371 x 218 x 167 mm (14.6 x 8.6 x 6.6 inch), excluding charging
cable, mounting bracket and cable holder
Net weight
3.9 kg*
Compliance/ certificate
CE, UKCA
*Depends on model configuration
