Delta AC MAX User Manual

v1.0.0
5
1.5 Model series
The following describes the segmentation used to describe the basic features of each available model:
EIAW - X XXK X X X X X XX
1 2 3 4 5 6 7 8
Segment Item Description
1
E: AU/NZ, EMEA, SEA,
G: China
J: Japan
T: Taiwan
U: Canada, US
Indicate the available region
2
From 1-99:
7: 7kW
11: 11kW
22: 22kW
Indicates the nominated maximum output power
3
S: Single phase
T: Three phase
Indicates the phase of input rating
4
B: Basic
S: Smart
P: Premium
Indicates the version of EVSE
5
U: SAE J1772 plug
E: IEC 62196-2 plug
S: IEC 62196-2 socket
H: IEC 62196-2 shutter
G: GB/T 20234.2 plug
Indicates the charging interface
6
From 1-9:
5: 5m
7: 7m
Indicates the cable length (0 for socket or shutter)
7
From A-Z:
A: Generation A
B: Generation B
Indicates the product generation
8 From 01-99 Indicates the serial code of EVSE
