Chapter 2 Introduction
5
Chapter 2 : Introduction
2.1 General Overview
The N series UPS is a single-phase on-line UPS providing reliable and consistent
sine-wave quality power to your electronic equipment. It adopts the latest technol-
ogy and the highest quality components providing output power factor up to 0.9, and
its efciency in on-line mode can reach at maximum 93%. The UPS not only pro-
vides safe, reliable and uninterrupted power to your sensitive electronic equipment
at all times, but also produces greater electronic power efciency at less cost. Its
compact design does not occupy much space and is easy to use. There are three
different ratings, 1kVA, 2kVA and 3kVA, for your selection.
2.2 Exterior & Dimensions
(Figure 2-1 : 1 kVA
Exterior & Dimensions)
(Figure 2-2 : 2/3 kVA
Exterior & Dimensions)
225mm
320mm
145mm
390mm
190mm
To Next Page
