Delta AS200 Series User Manual

Chapter 2 Specifications and System Configuration
2-6
2_
Model
Item
AS332T-A
AS332P-A
AS320T-B
AS320P-B
AS324MT-A
Response
time
OFF→ON
X0.0~X0.11: < 2.5μs
X0.12~X0.15: < 50μs
X0.0+–X0.3+/X0.0- to
X0.3-： < 0.125 μs
X0.4–X0.11: < 2.5μs
ON→OFF
X0.0~X0.11: < 2.5μs
X0.12~X0.15: < 50μs
X0.0+–X0.3+/X0.0- to
X0.3-： < 0.125 μs
X0.4–X0.11: < 2.5μs
Maximum input
frequency
X0.0~X0.11: 200 kHz
X0.12~X0.15: 10 kHz
X0.0+–X0.3+/X0.0- to
X0.3-: < 4 MHz
X0.4–X0.11: < 200 kHz
Input impedance
5.6 k Ω
Input signal
Voltage input
Sinking: The inputs are NPN transistors whose collectors are open collectors.
Sourcing: The inputs are PNP transistors whose collectors are open collectors.
Electrical isolation
Optocoupler
Input display
When the optocoupler is driven, the input LED indicator is ON.
Note: AS300N-A does not come with inputs/outputs.
 Electrical specifications for the outputs on AS300 Series.
Model
Item
AS332T-A
AS332P-A
AS320T-B
AS320P-B
AS324MT-A
Number of outputs
16 (Y0.0-Y0.15)
12 (Y0.0-Y0.11)
12 (Y0.0-Y0.11)
Connector type
MIL connectorMIL
connector
Removable
terminal blocks
MIL connector
Output form
Transistor-T (sinking)
Transistor-P (sourcing)
Y0.0+–Y0.3+/Y0.0- to Y0.3-: differential
input
Y0.4–Y0.11: Transistor-T (sinking)
Voltage
5-30 VDC
Y0.0+–Y0.3+/Y0.0- to Y0.3- : 5 VDC
Y0.4–Y0.11: 5-30VDC
Maximum
load
Resistance
0.1A/output,
1.6A/COM
0.1A/output,
1.2A/COM
Y0.0+-Y0.3+/Y0.0-Y0.3- : 20mA/output
(+ and – as a group, e.g. Y0.0+ and
Y0.0- is a group)
Y0.4-Y0.11:0.1A/output, 0.8A/COM
Inductance
N/A
Bulb
N/A
Maximum
output
frequency
*1
Resistance
Y0.0-Y0.11: 200 kHz
Y0.12-Y0.15: 100 Hz
Y0.0+–Y0.3+/Y0.0- to Y0.3- : 4 MHz
Y0.4–Y0.11: 200 kHz
Inductance
N/A
Bulb
N/A
Maximum
Response
time
OFF→ON
Y0.0~Y0.11: 2.5μs
Y0.12~Y0.15: 0.5ms
Y0.0+–Y0.3+/Y0.0- to Y0.3-: 0.125 μs
Y0.4–Y0.11: 2.5 μs
