AS Series Operation Manual
2-7
_2
 Electrical specifications for the inputs on AS200 Series. The signals passing through the inputs
are 24 VDC signals.
Model
Item
AS228P-A / AS228R-A / AS228T-A AS218PX-A / AS218RX-A / AS218TX-
A
Number of inputs
16 (X0.0-X0.15) 8 (X0.0-X0.7)
Connector type
Removable terminal blocks
Input type
Digital input
Input form
Direct current (sinking or sourcing)
Input voltage/ current
24 VDC, 5 mA
Action level
OFF→ON
>15 VDC
ON→OFF
<5 VDC
Response time
OFF→ON
X0.0–X0.7: < 2.5μs
X0.8–X0.15: < 50μs
ON→OFF
X0.0–X0.7: < 2.5μs
X0.8–X0.15: < 50μs
Maximum input frequency
X0.0–X0.7: 200 kHz
X0.8–X0.15: 10 kHz
Input impedance
3.9 k Ω
Input signal
Voltage direct input
Sinking: The inputs are NPN transistors whose collectors are open collectors.
Sourcing: The inputs are PNP transistors whose collectors are open
collectors.
Electrical isolation
Optocoupler
Input display
When the optocoupler is driven, the input LED indicator is ON.
Analog inputs
N/A
2
Analog input resolution
N/A
12bits
Analog input mode
N/A
-10V~10V (voltage mode) or
20mA~20mA (currentmode)
Analog linearity error
N/A
±1% (full scale)
Analog input impedance
N/A
≧1 MΩ (Voltage mode)
250 Ω (Current mode)
 Electrical specifications for the outputs on AS200 Series.
Model
Item
AS228R-A
AS218RX-A
AS228T-A
AS218TX-A
AS228P-A
AS218PX-A
Number of outputs
AS228 Series: 12 outputs (Y0.0-Y0.11)
AS218 Series 6 outputs (Y0.0-Y0.5)
Connector type
Removable terminal blocks
Output form
Relay
Transistor-T (sinking)
Transistor-P
(sourcing)
Voltage / current
240 VAC / 24 VDC 5-30 VDC 5-30 VDC
Leakage current
0uA <10uA
Maximum
load
Resistance
AS228
2A/output, 8A/COM
0.5A/output, 2A/COM
0.5A/output, 2A/COM
AS218
2A/output, 6A/COM 0.5A/output, 1.5A/COM
0.5A/output,
1.5A/COM
Inductance
Life cycle curve*
1
N/A
N/A
