Delta AS228R-A

Electrical specifications for the inputs
Model
Item
Pulse input External input
Number of inputs
4 (A+/B+, A-/B-) 2 (Z+/Z-)
Connector type
D-sub 15
Input current
5-24 VDC, 6-15 mA
Action
level
OFF→ON
3 V
ON→OFF
1 V
Maximum input
frequency
200 kHz
20 kHz
Input impedance
4.7 kΩ
Input signal
Signal signal: 5 – 24 VDC (sinking or sourcing) ; differential signal: 5 V
Input isolation
500 VAC
Input display
When the optocoupler is driven, the input LED indicator is ON.
Weight
138 g
Electrical specifications for the SSI input and output
Model
Item
SSI input SSI output
Number of inputs /
outputs
2 (DATA+/DATA-) 2 (CLK+/CLK-)
Connector type
D-sub 15
Voltage / Current
5 VDC, 1 mA
5 VDC, ±60 mA (max.)
Action
level
OFF→ON
V
ID
*1
≧ 0.2V
-
ON→OFF
V
ID
≦ 0.2V
-
Maximum
input/output
frequency
1.25 MHz
Input impedance
12 kΩ (terminal resistor 120 Ω)
-
Input signal
RS-422
Input isolation
500 VAC
Input display
When the optocoupler is driven, the input LED indicator is ON.
*1: V
ID
is the voltage difference between DATA+ and DATA-.
