Delta AS228R-A

9.8.18 SM Register (Class ID: 358 Hex)
 Service Code
Service Code Service Name
Support
Description
Class Attribute
Instance
Attribute
H’0E Get_Attribute_Single X V Read one attribute
H’10 Set_Attribute_Single X V Write one attribute
H’32 Read_Parameter X V Read Parameter
H’33 Write_Parameter X V Write Parameter
 Class
 Class ID：H’358
 Instance
 H’01：Instance Attribute, Bit Register
 When Instance = 1, the Instance Attributes are listed below.
Instance
Attribute
Name
Access
Rule
Data
Type
Values Description
H’00 SM0
Get/Set
BOOL H’00 SM0 bit register
H’01 SM1
Get/Set
BOOL H’00 SM1 bit register
H’02-H’FFE SM2-SM4094
Get/Set
BOOL H’00 SM2-SM4094 bit register
H’FFF SM4095
Get/Set
BOOL H’00 SM4095 bit register
