Function Button Description
for the slaves to power-on is less than the master does.
If not, do not select this option.
Items on the data exchange table:
Name Description
Item The number of the block for data exchange.
Enable Selects whether to enable the data exchange table when the data exchange is performed.
Station Address/
IP Address
The slave station address for the data exchange table. You can set one address for multiple
data exchange tables. It is a station address under the COM1 and COM2 tabs, and an IP
under the Ethernet tab.
Local Address The device address range used by the master in the data exchange table
: Input: the data block where the master reads from a slave
: Output: the data block where the master writes to a slave
Remote Address
This is the device address range used by a slave in the data exchange table.
The device range is in hexadecimal if the slave in the data exchange table is a user-defined
Modbus Device.
Quantity
This is the size of the data exchange table, which is consistent with the result calculated from
the device range.
