Delta AS332P-A

For AS100 Series PLC CPU: install the removable terminal block on the module as shown below.

Installation
Align the terminal block at the printed circuit board, and press it into the module.

Removal
Use a screwdriver to separate the terminal block from the module and then pull the terminal block out as
shown below.
