4.3.4 Changing a Module
1. Take the removable terminal block out of the module and pull the clip out from the DIN rail as the
image shown below.
2. Remove the module to be changed out.
3. Slide the new module in as the image shows below.
4.3.5 Installing and Removing an Extension Card for AS300 PLC CPU
A. AS-F232/AS-F422/AS-F485/AS-F2AD/AS-F2DA/AS-FCOPM
1. Installation
Push the extension card into the extension card slot until you hear a click.
