Delta AS332P-A

4.8.2 Wiring Digital Output Terminals
4.8.2.1 Output Circuits
There are three types of output units. They are relay outputs, transistor outputs, and differential outputs.
1. Relay output
250VAC
2A
I/O Relay
Y0.0
C0
I/O Relay
Y0.0
C0
30VDC
2A
2. Transistor output
5~3 0VDC
0.5A
C0
Y0.
0
+
I/O( )Sink
Y0.0
C0
+
5~3 0VDC
0.5A
I/O(Sou rce )
3. Differential output
FP
Y0.3+
Y0.3-
100k
2k
ASDA-A2
Shielded c able *1
HSIGN 4 6
/HS IGN
40
2k
FP
Y 0.0+
Y0.0 -
ASDA-A2
Shielded c able *1
SIGN 36
/SIGN 37
