Delta AS332P-A

 Electrical specifications for the outputs on a digital input/output module
Model
Item
08
AN01
R-A
16AN01
R-A
16AP11
R-A
08
AN01
T-A
16AN01
T-A
16AP11
T-A
08AN01
P-A
16AN01
P-A
16AP11
P-A
Number of outputs
8
16
8
8
16
8
8
16
8
Connector type
Removable terminal block
Output type
Digital output
Output form
Relay-R
Transistor-T (sinking)
Transistor-P (sourcing)
Voltage/ current
240 VAC/24 VDC
5–30 VDC
5–30 VDC
*2
Leakage current
0uA <10uA
<250uA (@V1.00A0)
<10uA (@V1.00A1)
Max. inrush current
NA Overcurrent protection
7.5A
(Tested condition: Ta =
25
0
C, V
DS
= 30VDC and
pulse duration = 1ms)
Maximum
load
Resistance
2A/output, 8A/COM
0.5A/output, 4A/COM 0.5A/output, 4A/COM
Inductance
Life cycle curve*
2
12 W (24 VDC) 12 W (24 VDC)
Bulb
20 W (24 VDC)
100 W (230 VAC)
2 W (24 VDC) 2 W (24 VDC)
Minimum load
1 mA / 5V
Maximum
output
frequency
*1
Resistance
1 Hz 100 Hz 100 Hz
Inductance
0.5 Hz 0.5 Hz 0.5 Hz
Bulb
1 Hz 10 Hz 10 Hz
Maximum
Response
time
OFF→ON
< 10 ms < 0.5 ms < 0.5 ms
ON→OFF
< 10 ms < 0.5 ms < 0.5 ms
Output isolation
1500 VAC 500 VAC
Weight
120 g 158 g 138 g 100 g 122 g 120 g 100 g 123 g 120 g
Model
Item
32AN02T-A 64AN02T-A
Number of outputs
32
64
Connector type
MIL connector
Output type
Digital output
Output form
Transistor-T (sinking)
Output voltage
5–30 VDC
Leadage current
<10uA
Max. inrush current
Overcurrent protection
Maximum
load
Resistance
0.1A/output, 3.2A/COM
Inductance
N/A
Bulb
N/A
Minimum load
1 mA / 5V
Maximum output
frequency
*1
100 Hz (resistance)
Maximum
Response
time
OFF→ON
< 0.5 ms
ON→OFF
Output isolation
500 VAC
