Delta AS332P-A User Manual

 AS06XA-A
Electrical specifications
Module name
AS06XA-A
Number of
inputs/outputs
Inputs: four; Outputs: two
Analog-to-digital
conversion
Voltage input/Current input; Voltage output/Current output;
Supply voltage
24 VDC (20.4 VDC–28.8 VDC) (-15% to +20%)
Connector type
Removable terminal block
Conversion time
2ms/channel; for FW V1.02.00 or later, upgraded to 1 ms/channel
Isolation
An analog circuit is isolated from a digital circuit by a digital integrated circuit/an
optocoupler, but the analog channels are not isolated from one another.
Isolation between a digital circuit and a ground: 500 VAC
Isolation between an analog circuit and a ground: 500 VAC
Isolation between an analog circuit and a digital circuit: 500 VAC
Isolation between the 24 VDC and a ground: 500 VAC
Weight
145 g
Functional specifications for the analog-to-digital conversion
Analog-to-Digital
Conversion
Voltage Input
Rated Input Range
-10 V ~ +10 V
0 V ~ 10 V
±5 V
0 V ~ 5 V
1 V ~ 5 V
Rated
Conversion Range
K-32000
~
K32000
K0
~
K32000
K-32000
~
K32000
K0
~
K32000
K0
~
K32000
Hardware Input Limit*
1
-10.12V
~
10.12V
-0.12V
~
10.12V
-5.06V
~
5.06V
-0.06V
~
5.06V
0.95V
~
5.05V
Conversion Limit*
2
K-32384
~
K32384
K-384
~
K32384
K-32384
~
K32384
K-384
~
K32384
K-384
~
K32384
Error Rate
Room Temperature: ±0.2% ; Full Temperature Range: ±0.5%
Hardware Resolution
16 bits
Input Impedance
2MΩ
Absolute Input Range*
3
±15 V
*1: If the input signal exceeds the hardware input limit, the module only shows the maximum value. If the input
signal is below the lower limit, it only shows the minimum value. And an error flag will be set.
*2: If the input signal exceeds the hardware input limit, it also exceeds the conversion limit and a conversion
limit error appears. For example in the voltage input mode (-10 V to +10 V), when the input signal is 10.15 V,
exceeding the hardware upper limit, it also exceeds the conversion upper limit. The module uses the upper
limit value (32384) as the input signal and a conversion limit error appears.
*3: If an input signal exceeds the absolute range, it might damage the channel.
