ASDA-M Chapter 3 Wiring
Revision December, 2014 3-21
DO Signal
Name
Operation Mode
Pin No
Function
Wiring
Method
(Refer to
3.3.3)
＋ －
SDO_F ALL - -
Output the status of bit15 of P4-06
C5/C6/
C7/C8
NOTE
1) For example, if the user selects PR mode, pin 3 and 2 are HOME. If
the user selects S mode, pin 3 and 2 are TSPD.
2) The unlisted Pin No means the signal is not the preset one. If users
want to use it, parameters need to be changed and set as the
desired ones. Please refer to Section 3.3.4 for further details.
