Delta DVP-SS2 User Manual

3. Instruction Set
3-169
 Available for the followings
Series
ES2/
EX2
ES2-C ES2-E
12SA2/
SX2
SS2 12SE 26SE 28SA2
Firmware
version
V3.42 V3.48 V1.40 V2.86 -- V2.02 V1.2 V2.9

Special D/M Devices Corresponding to the Marking and Masking Function
Output
number
Marking
deceleration
flag
External
input
point
Ramp-up
time
Ramp-
down
time
Starting/
Stopping
frequency
Number of
ramp-down
pulses
after marking
Front
masking
Back
masking
Y0 M1156 X4 D1343 D1348 D1340 D1232/D1233
D1026/
D1027
D1100/
D1101
Y1 M1157 X5 NA NA NA D1236/D1237
D1154/
D1155
D1156/
D1157
Y2 M1158 X6 D1353 D1349 D1352 D1234/D1235
D1135/
D1136
D1102/
D1103
Y3 M1159 X7 NA NA NA D1238/D1239
D1158/
D1159
D1160/
D1161
It does not support separating the ramp up and ramp down nor does it support setting up the
start/stop frequency.
 Y1 and Y3 relative parameters for fixed slope function:
Output Flag for fixed slope
Special device for the
maximum frequency
Y1 M1606 D1988, D1989
Y3
M1607
D1990, D1991
 For EC5 Series:
Output Flag for fixed slope
Special device for the
maximum frequency
Y0
M1604 D1410, D1411
Y2
M1605 D1412, D1413
Y4
M1606 D1988, D1989
Y6
M1607 D1990, D1991
Note: If the values in the device where stores pulse number for masking in the front for Y0-Y3
is zero or less than -4 or equals to -4, it indicates the marking and masking functions in the
front are disabled. On the other hand, if the values is greater than 0 or between -1 to -3, it
indicates the marking and masking functions in the front are enabled. If the values in the
