LTL-XL Retroreflecto
m
eter
DELTA
The menu tree
Figure: 5
–
The
m
en
u tree
SE
TTINGS:
USER
DATE & TIME
DISPLAY
SOUND
POWER
LANGUAGE
TEMPERATURE
SMART
AUX
SETUP
SERIES-ID:
ACTIVATE
SELECT NE
W
EDIT
DELETE
PRESET MARK
AUX:
GPS
SOUND:
KEY CLICK
SOUNDS
BEEP
DISPLAY:
BACKLIGHT
DIMMER
DIM LEVEL
BACKGROUND
DATE & TIME:
TIME FORMAT
DATE FORMAT
SET TIME/DATE
TIME ZONE
SYNC TO GPS
USER:
SELECT
EDIT
NEW
DELETE
SEL. AT START
DIAGNOSTICS:
INSTRUMENT
BATTERY
BOARDS
GPS
SYSTEM
AVERAGE:
AVERAGE
TYPE
NUMBER
RESET
LOG:
CLEAR DATA
VIEW LOG
CLEAR LOG:
LAST DATA
ALL DATA
SERIES DATA
VIEW LOG:
LAST DATA
ALL DATA
SERIES DATA
MEAS. TYPE:
RL
Qd
WET TIMER
TIMER ALARM
HELP:
HELP ON KEYS
HELP ON MENU
HELP ON MEASU
REMENT
HELP ON SERI
ES SELECT
ROAD MARKING
SELECT
HELP ON USER
SELECT
HELP ON EDITING
HELP ON AVER
AGING
HELP ON GPS
HELP ON SETTINGS
MENU
HELP ON SERI
ES-ID MENU
HELP ON LOG MENU
POWER:
AUTO
SLEEP
AUTO OFF
MAIN MENU
SETTINGS
MEASURE TYP
E
SERIES-
ID
LOG
AVERAGE
DIAGNOSTICS
HELP
AUTOPRINT
17
19
Table of Contents
Default Chapter
5
Table of Contents
5
Section 1
7
Operating Information
7
LTL-XL Introduction
7
LTL-XL Retroreflectometer Features
8
Options
8
Getting Started
9
Important Guide Lines for the Correct Use of the LTL-XL
12
Section 2
13
General Information
13
Measurements
13
Notes on Error Sources
13
High Temperature Conditions
14
Section 3
15
The User Interface
15
Display and Keyboard Layout
15
Measurement Display / HOME Screen
15
Upper Icon Row
15
Lower Icon Row
16
Push Buttons
16
The Menu Tree
18
Setting up for Measurements
19
Selecting a User ID
19
Selecting a Road Marking Icon
21
Setting the Date and Time
21
Setting the Dimmer and Back Light (Display)
22
Setting the Sound Level
23
Auto Sleep (Power)
23
Auto off (Power)
24
Setting the Language
24
Setting the Temperature Unit
24
Setting the SMART Key Function
24
Using GPS (Optional)
24
Setup (Basic and Advanced)
26
Measure Type
27
R L & Qd
27
Wet Timer
27
Timer Alarm
27
Series ID
28
Working with Series ID
28
Activate
28
Selecting a Series ID
28
Enter a New Series ID
29
Removing a Series ID
29
Presetting the Road Marking Icon
29
The Log
31
Clearing Data in the Log
31
Viewing the Log
32
View Series Data
33
Other Settings
34
Average Function
34
Editing Names
35
Auto Print
35
Diagnostics
35
The Help System
35
Errors and Warnings
36
RSC Software Program
36
Section 4
37
Maintenance
37
General Care
37
Protection Window
37
Battery
37
Fuses
39
Lamp
39
Calibration Unit
40
Calibration
41
Printer (Optional)
43
Mounting the Wheel Unit (Option)
44
Appendix A
45
Communication Facilities
45
RSC Software Program
45
Appendix B
46
Environmental Characteristics
47
Mechanical Characteristics
47
Specification
46
General Characteristics
46
Appendix C
48
Delivery
48
Other manuals for Delta LTL-XL
Quick Guide
2 pages
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Delta LTL-XL and is the answer not in the manual?
Ask a question
Delta LTL-XL Specifications
General
Brand
Delta
Model
LTL-XL
Category
Measuring Instruments
Language
English
