4.5.3. 干接点之连接
RPI M30A/ M50A机种提供2组连动的干接点，其触发条件可由使用者自定
义，设定方式请参考章节5.2.7.5 Dry Contact。
图4-19 干接点连接
Dry
Contact 1
Dry
Contact 2
114
配 线
