TP70P-211LC1T/TP04P-20EXL1T Operation Manual
3-4
_3
Excitation
voltage
Eigenvalue
modes
Eigenvalue
(mV/V)
Excitation
voltage
Eigenvalue
modes
Eigenvalue
(mV/V)
Excitation
voltage
Eigenvalue
modes
Eigenvalue
(mV/V)
Excitation
voltage
Eigenvalue
modes
Eigenvalue
(mV/V)
9.5
0
0.5
8.0
0
0.5
6.0
0
0.5
3.5
0
0.5
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
3
3
3
4
3
4
3
4
4
4
4
8
4
8
4
8
5
6
5
16
5
16
5
16
6
7
6
32
6
32
6
32
7
10
7
50
7
64
7
64
8
12
8
75
8
128
8
128
9
16
9
100
9
256
9
256
Excitation
voltage
Eigenvalue
modes
Eigenvalue
(mV/V)
Excitation
voltage
Eigenvalue
modes
Eigenvalue
(mV/V)
Excitation
voltage
Eigenvalue
modes
Eigenvalue
(mV/V)
Excitation
voltage
Eigenvalue
modes
Eigenvalue
(mV/V)
9.0
0
0.5
7.0
0
0.5
5.0
0
0.5
2.0
0
0.5
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
3
4
3
4
3
4
3
4
4
8
4
8
4
8
4
8
5
12
5
16
5
16
5
16
6
16
6
32
6
32
6
32
7
24
7
64
7
64
7
64
8
32
8
128
8
128
8
128
9
48
9
200
9
256
9
256
(3) Response Time Mode: setting range is from 0 to 8; see the modes and their corresponding response times below.
Response time
mode
0 1 2 3 4 5 5 7 8
Response time (ms)
2.5 10 16 20 50 60 100 200 400
(4) Filter Mode: setting range is from 0 to 2; see the modes and their descriptions below.
Filter Mode
0 1 2
Description
No filter Maximum value filter Average value filter
(5) Filter Parameter: setting range is from 0 to 8. The bigger the value is set, the more frequent and stronger the
filtering is in the maximum value filter mode.
(6) Weight Limit: setting range is from 0 to 2
32
(32-bit value); if the value set is out of range, the system sends out an
status code.
(7) Upper Zero Limit: setting range is from 0 to 32767 (16-bit value); zero upper limit is defined here.
(8) Lower Zero Limit: setting range is from -1 to -32768; zero lower limit is defined here.
(9) Stability Checking Times: setting range is from 1 to 500; the system checks if the value is within its setting range
for a number of times that is set here.
(10) Stability Checking Range: setting range is from 1 to 10000; the system determines if the status is stable by
checking if the measured value is within the variation range that is set here. For example, when the value is set to
10, the system checks if the measured value is within this variation range (±10). When it is in the range, the status is
stable and the Motion in the bulletin is highlighted in a green block.
