Delta TP70P-211LC1T User Manual

Chapter 1 Product Introduction
1-3
1__
1.3 Model Descriptions
1.3.1 TP70P-211LC1T
Type
7-inch Touch Panel HMI with Built-in PLC
Model Name
TP70P-211LC1T
Description
Digital
Input / Output
24VDC, 5mA, 17 inputs
12 ~ 24VDC, 0.5A/output, 2.5A/COM, Transistor-
T (sinking) (NPN), 24
outputs
Analog Output
4 analog channel; current 0 ~ 20mA / 4 ~ 20mA
Analog / Temperature
Measurement Input
2 input channel; 0 ~ 5V, 0 ~ 10V, 0 ~ 50mV, 0 ~ 20mA, 4 ~ 20mA; applicable
sensors: Pt100 / JPt100 / Pt1000 / Ni100 / Ni1000 / LG-Ni1000 / Cu50 /
Cu100; 16-bit resolution
Load Cell Input
1-channel, 4-wire/6-wire load cell sensor
Highest precision: 0.01%。ADC Resolution: 24 bits
Conversion time: selectable 2.5 ~ 400ms
Variable excitation voltage: 2 ~ 9.5V/250mA
Communication Port
Isolated USB (COM1) & Isolated RS-485 (COM2/COM3)
