5.1 Devices
The list is specific for TP70P-211LC1T and TP04P-20EXL1T only.
Item Description
Control method
Stored program, cyclic scan system
I/O processing method
Batch processing method (when END instruction is executed)
Execution speed
LD instrucitons at 0.76
µ
s
Program language
Instruction, Ladder Diagram (LD), Sequential Funciton Charts (SFC)
Program capacity
TP70P-211LC1T: 4K Steps
TP04P-20EXL1T: 8K Steps
Relay Bit device
X External input relay
TP04P-20EXL1T: X0 ~ X7, X20
TP70P-211LC1T: X0 ~ X7, X10 ~ X17, X20
Y External output relay
TP04P-20EXL1T: Y0 ~ Y7, Y20 ~ Y27
TP70P-211LC1T: Y0 ~ Y7, Y10 ~ Y17, Y20 ~ Y27
M
Auxiliary relay
General
M0~M511: 512 auxiliary relays (*1)
M768~M999: 232 auxiliary relays (*1)
M2000~M2047: 48 auxiliary relays (*1)
4096 auxiliary
relays in total
Latching
M512~M767: 256 auxiliary relays (*2)
M2048~M4095: 2048 auxiliary relays (*2)
Special
M1000~M1999: 1000 auxiliary relays
Some of them are latching auxiliary relays
T
Timer
100 ms (If M1028 is
ON, T64~T126 will
be 10 millisecond
timers.)
T0~T126: 127 timers (*1)
T128~T183: 56 timers (*1)
251 timers in
total
T184~T199 (for subroutines): 16 timers (*1)
T250~T255 (accumulation): 6 timers (*1)
10 ms
T200~T239: 40 timers (*1)
T240~T245 (accumulation), 6 timers (*1)
Relay Bit device
C
Counter
16-bit up counter
C0~C111: 112 counters (*1)
C128~C199: 72 counters (*1)
C112~C127: 16 counters (*2)
140 counters in
total
32-bit up/down
counter
C200~C223: 24 counters (*1)
C224~C232: 9 counters (*2)
C233~C234: 2 counters (*2)
C237~C250: 14 counters (*2)
C252~C255: 3 counters (*2)
32-bit high-speed
up/down counter
C235, C236: one-phase one-input, 2 counters (*2)
3 counters in
total
C251: two-phase two-input, 1 counter (*2)
Only double and quad frequency are supported.
S
Step
ping
relay
Initialization
S0~S9: 10 stepping relays (*2)
1024 stepping
relays in total
