TP70P-211LC1T/TP04P-20EXL1T Operation Manual
5-14
_5
Spec
ial
M
Content
OFF

ON
STOP

RUN
RUN

STOP
Attrib. Latched Default
M1063 System error message 4 OFF - - R NO OFF
M1064 Incorrect use of operands OFF OFF - R NO OFF
M1065 Syntax error OFF OFF - R NO OFF
M1066 Loop error OFF OFF - R NO OFF
M1067 Program execution error OFF OFF - R NO OFF
M1068 Execution error locked (D1068) OFF - - R NO OFF
M1072 PLC status (RUN/STOP), ON = RUN OFF ON OFF R/W NO OFF
M1075 Error occurring when write in Flash ROM OFF - - R NO OFF
M1080 COM2 monitor request OFF - - R/W NO OFF
M1081 Changing conversion mode for FLT instruction OFF - - R/W NO OFF
M1088
Matrix comparison; comparing between equivalent values
(M1088 = ON) or different values (M1088 = OFF).
OFF OFF - R/W NO OFF
M1089
The end of matrix comparison; when the comparison
reaches the last bit, M1089 = ON.
OFF OFF - R NO OFF
M1090
The start of matrix comparison; when the comparison
starts from the first bit, M1090 = ON.
OFF OFF - R NO OFF
M1091
Matrix searching results; when finding matched results,
comparison will stop immediately and M1091 = ON.
OFF OFF - R NO OFF
M1092
Pointer error; when the pointer Pr exceeds the
comparison range, M1092 = ON
OFF OFF - R NO OFF
M1093
Matrix pointer accumulated flag. Adding 1 to the current
value of the Pr.
OFF OFF - R/W NO OFF
M1094
Matrix pointer clear flag. Clear the current value of the Pr
to 0
OFF OFF - R/W NO OFF
M1095 Carry flag for matrix rotation/shift/output. OFF OFF - R NO OFF
M1096 Borrow flag for matrix rotation/shift/input OFF OFF - R/W NO OFF
M1097 Direction flag for matrix rotation/displacement OFF OFF - R/W NO OFF
M1098 Counting the number of bits which are “1” or “0” OFF OFF - R/W NO OFF
M1099 ON when the bits counting result is “0” OFF OFF - R/W NO OFF
M1120
Retaining the communication setting of COM2 (RS-485),
D1120 cannot be modified, when M1120 is set.
OFF OFF - R/W NO OFF
M1121
Data waiting to be sent via COM2 (RS-485)
OFF ON - R NO OFF
M1122
Request of sending via COM2 (RS-485)
OFF OFF - R/W NO OFF
M1123 Data received completely via COM2 (RS-485) OFF OFF - R/W NO OFF
M1124
Waiting to receive data via COM2 (RS-485)
OFF OFF - R/W NO OFF
M1125
Reset communication status of COM2 (RS-485)
OFF OFF OFF R/W NO OFF
M1126
set STX/ETX as user defined or system defined for
COM2 (RS-485)
OFF OFF OFF R/W NO OFF
