Delta VFD-B Series User Manual

Appendix B Accessories_VFD-B Series
Revision 10/2005, BE13, SW V4.08 B-27
3. Control Terminals Block Designations.
OC
TP
A
/O
B/O
0V
12V
0V
A
A
B
Connect to the
Series Control Board
VFD
Select the input
power and the
output type of the
Encoder
PG-03 FSW2
B
G
B
A
4. Encoder types
Output Types of the Encoder FSW2 Switch
Output Voltage
O/P
0V
VCC
OC
TP
Open Collector
O/P
0V
VCC
OC
TP
Line Driver
Q
Q
OC
TP
Complimentary
O/P
0V
VCC
OC
TP

Delta VFD-B Series Specifications

General

Series	VFD-B
Cooling Method	Fan cooling
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Control Mode	V/F control, Sensorless Vector Control
Communication	RS-485
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH (non-condensing)
Altitude	1000m (Derating required above 1000m)
