Delta VFD-B Series User Manual

Appendix B Accessories_VFD-B Series
Revision 10/2005, BE13, SW V4.08 B-37
460V DC Choke
Input voltage kW HP DC Amps Inductance (mh) MTE CAT. NO
0.75 1 4 25.00 4RB004
1.5 2 9 11.50 9RB004
2.2 3 9 11.50 9RB004
3.7 5 12 6.00 12RB004
5.5 7.5 18 3.75 18RB004
7.5 10 25 4.00 25RB005
11 15 32 2.68 32RB003
15 20 50 2.00 50RB004
18.5 25 62 1.20 62RB004
22 30 80 1.25 80RB005
30 40 92 Built-in --
37 50 110 Built-in --
45 60 125 Built-in --
55 75 200 Built-in --
460Vac
50/60Hz
3-Phase
75 100 240 Built-in --

Delta VFD-B Series Specifications

General

Series	VFD-B
Cooling Method	Fan cooling
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Control Mode	V/F control, Sensorless Vector Control
Communication	RS-485
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH (non-condensing)
Altitude	1000m (Derating required above 1000m)
