Delta VFD-B Series User Manual

Appendix B Accessories_VFD-B Series
B-40 Revision 10/2005, BE13
Line Fuse
Model
I (A)
Input
I (A)
Output
I (A) Bussmann P/N
VFD220B23A 90 90 175 JJN-175
VFD220B43A 49 45 100 JJS-100
VFD220B53A
37 34 75 JJS-70
VFD300B23A 110 120 225 JJN-225
VFD300B43A 60 60 125 JJS-125
VFD300B53A
41 41 75 JJS-70
VFD370B23A 142 145 250 JJN-250
VFD370B43A 63 73 150 JJS-150
VFD370B53A
52 52 100 JJS-100
VFD450B43A 90 91 175 JJS-175
VFD450B53A
62 62 125 JJS-125
VFD550B43A/C 130 110 250 JJS-250
VFD550B53A
95 80 175 JJS-175
VFD750B43A/C 160 150 300 JJS-300
VFD750B53A
117 100 200 JJS-200

Delta VFD-B Series Specifications

General

Series	VFD-B
Cooling Method	Fan cooling
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Control Mode	V/F control, Sensorless Vector Control
Communication	RS-485
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH (non-condensing)
Altitude	1000m (Derating required above 1000m)
