Delta VFD-B Series User Manual

Chapter 2 Installation and Wiring_VFD-B Series
2-8
Revision 10/2005, BE13, SW V4.08
Frame D: VFD150B23A/43A/53A, VFD185B23A/43A/53A, VFD220B23A/43A/53A
13.0 [0.51]
10.0 [0.39]
R
5
.
0
[
R
0.
2
0
]
403.8 [15.90]
384.0 [15.12]
4
2
.
0
[ 1
.
6
5
]
(2
X
)
250.0 [9.84]
226.0 [8.90]
2
8
.
0[
1
.
1
0]
205.4 [8.08]
10.0 [ 0.39]

Delta VFD-B Series Specifications

General

Series	VFD-B
Cooling Method	Fan cooling
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Control Mode	V/F control, Sensorless Vector Control
Communication	RS-485
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH (non-condensing)
Altitude	1000m (Derating required above 1000m)
