Chapter 7 Option Cards | VFD-ED
7-2 EMED-PGABD-2
7-2-1 Product Profile
NOTE:
1.
Applicable encoder: A/B/Z and U/V/W Absolute Encoders
2.
Screw specification
Wire
Gauge
0.21.5 mm
2
(3016 AWG)
Torque 1.6 kg-cm (1.4 Ib-in.)
unit: mm [inch]
15.5 [0.61]<2X>
47.0 [1.85]<2X>
53.0 [2.09]
19.0 [0.75]
30.0 [1.18]
105.0 [4.13]<2X>
109.0 [4.29]
21.9 [0.86]
Ø
4
.0
0
.1
6
]
<
3X>
Ø
3
.
5
[
Ø
0.
1
4]
Dimension
Diagram
