Delta VFD-ED Series User Manual

Appendix C. Revision HistoryVFD-ED
C-1
Appendix C. Revision History
Firmware Version: V1.11
Issued Edition: 00
Issued Date: June, 2023
Added
Descriptions Chapters
 Added notes for airflow and heat dissipation for single and multiple drive installation Section 2-2
 Added maximum and minimum wire gauge, screw size and tightening torque for
ground terminal.
 Added recommended wires when installing at an ambient 50°C or above
environment
Section 4-2
 Added wiring diagram for frequency division output
Section 7-2-6
Section 7-3-5
Section 7-4-5
 Added links for Certifications and Declaration of Conformity (Doc) Section 8-3
 Added data value in tables for derating curves Section 8-5

Added rollback function parameters in Starting stage.

Added Pr.07-29 for comfort function in Stopping stage.
Section 10-4
 Pr.00-04: Added setting value 40 (elevator actual speed m/s) and display illustration

Pr.00-09: Added block diagrams for each control mode
Pr. Group 00
 Pr.01-08: Added SVC control mode Pr. Group 01
 MO40: Added descriptions regarding use with Pr.02-43
 Added multi-function input #MI57, MI59, and multi-function output #MO50, MO51,
MO52
 Pr.02-34: Added related descriptions when actual output H > Pr.02-34, and
descriptions regarding setting range and unit varying with Pr.00-10.
 Added Pr.02-40 to Pr.02-42 (direct docking mode only), and Pr.02-43 (Speed
Reached Bandwidth)
Pr. Group 02

Pr.05-16, Pr.06-01, Pr.06-26, Pr.09-02, Pr.10-03, Pr.10-09: Added notes regarding
setting value “fault and ramp to stop”
Pr. Group 05,
06, 09, 10
 Pr.06-50, Pr.06-51, Pr.06-52: Added cross-reference fault codes ocA, ocd, ocn,
ocS, GFF
 Pr.06-52: Added notes regarding minimum time interval

Pr.06-72: Added two methods 1. ARD or UPS 2. Battery used as EPS
Pr. Group 06
 Added Pr.07-31 to Pr.07-37 brake torque test functions Pr. Group 07
 Added Pr.11-21 (filter time display settings on built-in keyboard panel) Pr. Group 11
 Added warning codes: LS, bttA, bttn, bttS Chapter 13
 Added fault codes: OPHL (U/V/W phase output phase loss), LSS, LSo, btt, bttE
Pr. Group 06
Chapter 14
