Delta VFD-ED Series User Manual

Appendix C. Revision HistoryVFD-ED
C-2
Updated
Descriptions Chapters
 Updated Personal Repair Request service link Section 1-4
 Updated data value for MI1 to MI8 Default (NPN Mode) Section 5-3
Updated recommended filter selections for the following models:
 VFD055ED43S: from EMF033A43A to EMF018A43A
 VFD075ED43S: from EMF033A43A to EMF018A43A

VFD150ED43S: from B84143D0075R127 to EMF033A43A
Section 6-6
 Updated information on digital keypad from KPC-CE01 to KPC-CC01
Section 6-7
Section 9-4
 Updated IFD6530 driver download link Section 6-8
 Deleted discontinued option cards: EMED-PGABD-1, EMED-PGHSD-1, EMED-
PGHSD-2
Section 7-1-2
Section 7-2 to 7-4
Section 10-3
Pr. Group 10, 11
Section 14
 Updated terminal DGND to GND in wiring diagrams Section 7-2 to 7-4

Maximum external power is 12V, deleted 24V related information
 Updated wiring diagrams in external power

Updated note item 3: from A, B, Z to /A, /B, /Z
Section 7-2-3
 Maximum output voltage: deleted “three-phase”

Output frequency range: updated output frequency upper limit to 299 Hz
Section 8-1
Section 8-2

Updated speed control range: 1: 100 (up to 1:1000 when using PG card) to 1:50
(up to 1:1000 when using PG card)
 Maximum output frequency: updated output frequency upper limit to 299.00 Hz
 Categorized Certifications into EMC Directive, Production Compliance,
Production Certifications, and Safety Certification.
Section 8-3
 Updated digital keypad KPC-CC01 to latest

Simplified Chinese language is not supported in this version.
Chapter 09

Updated function parameters in All stage.

Updated parameters for comfort function in Starting stage.
Section 10-4
 Pr.01-38: Updated the process and steps for two methods of sending leveling
signals
 Updated drive’s output frequency upper limit: Pr.01-00, Pr.01-01, Pr.01-03,
Pr.01-05, Pr.01-07, Pr.01-09, Pr.01-10, Pr.01-11, Pr.01-22, Pr.01-23, Pr.01-29,
Pr.01-39
Chapter 10
Pr. Group 01

Multi-function input MI#39: Updated cross-reference from Pr.03-01 to Pr.03-00
 Pr.02-34: Updated drive’s output frequency upper limit to 299.00 Hz, and deleted
tolerance range plus–minus sign
 Pr.02-38, Pr.02-39: Updated elevator timing diagram
 Pr.02-25, Pr.02-26, Pr.02-27, Pr.02-28, Pr.02-34: Updated drive’s output
frequency upper limit
Pr. Group 02
 Pr.03-15: Updated load compensation auto-tuning process Pr. Group 03
 Pr.04-00 to Pr.04-15: Updated drive’s output frequency upper limit
Chapter 10
Pr. Group 04
