Delta VFD-ED Series User Manual

Chapter 10 Auto-tuning Process | VFD-ED
10-26
Stage
Function Pr. Control Mode Description Settings Default
Decelerating
Multi-step
Speed
01-13
VF, VFPG, SVC,
FOCPG, FOCPM
Decel. Time 1 0.00–600.00 sec. 2.00
01-26
VF, VFPG, SVC,
FOCPG, FOCPM
S-curve for
Deceleration
Begin Time S3
0.00–25.00 sec. 1.00
01-27
VF, VFPG, SVC,
FOCPG, FOCPM
S-curve for
Deceleration
Arrival Time S4
0.00–25.00 sec. 1.00
Comfort
01-04
VF, VFPG
Second Output
Voltage Setting
230V models: 0.1–255.0 V
460V models: 0.1–510.0 V
5.0
10.0
01-06 VF, VFPG
Third Output
Voltage Setting
230V models: 0.1–255.0 V
460V models: 0.1–510.0 V
5.0
10.0
11-07 FOCPG, FOCPM
Low Speed
Bandwidth
1–40 Hz 10
11-08 FOCPG, FOCPM
High Speed
Bandwidth
1–40 Hz 10
Leveling
Comfort 11-07 FOCPG, FOCPM
Low Speed
Bandwidth
1–40 Hz 10
Stopping
Delay Time
02-30
VF, VFPG, SVC,
FOCPG, FOCPM
Brake Engage
Delay Time when
Elevator Stops
0.000–65.000 sec. 0.250
02-32
VF, VFPG, SVC,
FOCPG, FOCPM
Magnetic
Contactor Release
Delay Time
between Drive and
Motor
0.010–65.000 sec. 0.200
Elevator
Parking
01-29
VF, VFPG, SVC,
FOCPG, FOCPM
Switch Frequency
for S3/S4
Changes to S5
0.00–299.00Hz 0.00
01-30
VF, VFPG, SVC,
FOCPG, FOCPM
S-curve for
Deceleration
Arrival Time S5
0.00–25.00 sec. 1.00
01-31
VF, VFPG, SVC,
FOCPG, FOCPM
Deceleration Time
when Operating
without RUN
Command
0.00–600.00 sec. 2.00
Comfort
07-29
FOCPG, FOCPM
Time for
Decreasing Torque
at Stop
0.000–5.000 sec. 0.000
11-19 FOCPG, FOCPM
Zero Speed
Parking Bandwidth
1–40 Hz 10
Torque
Check
02-33
VF, VFPG, SVC,
FOCPG, FOCPM
External Terminal
Output Current
Level
0–100%
(motor drive rated current)
0
