Delta VFD-ED Series

Chapter 11 Summary of Parameter Settings | VFD-ED
11-5
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
8: FOC Permanent Motor control (FOCPM)
 00-10 Speed Unit
0: Hz
1: m/s
2: ft/s
3: Direct docking mode only
◆
0 ○ ○ ○ ○ ○
00-11
Output Direction
Selection
0: FWD: counterclockwise, REV: clockwise
1: FWD: clockwise, REV: counterclockwise
0 ○ ○ ○ ○ ○

00-12
Carrier Frequency
2–15 kHz
12
○
○
○
○
○
 00-13
Automatic Voltage
Regulation (AVR)
Function
0: Enable AVR
1: Disable AVR
2: Disable AVR when deceleration stop
0 ○ ○ ○ ○ ○
 00-14
Master Frequency
Command Source
1: RS-485 serial communication or digital
keypad (KPC-CC01)
2: External analog input (Pr.03-00)
3: Digital terminal inputs (Pr.04-00–Pr.04-15)
4: Direct docking mode only
◆
1 ○ ○ ○ ○ ○
 00-15
Operation
Command Source
1: External terminals
2: RS
-485 serial communication or digital
keypad (KPC-CC01)
1 ○ ○ ○ ○ ○
