Delta VFD-ED Series

Chapter 11 Summary of Parameter Settings | VFD-ED
11-17
05 IM Parameters
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
05-00 Motor Auto-tuning
0: No function
1: Dynamic test (Rs, Rr, Lm, Lx,
no-load current) (Motor runs)
2: Static test (Motor does not
run)
0
○
05-01 Motor Rated Current (40–120%) * Pr.00-01 Amps #.##
○
○ ○ ○
05-02 Motor Rated Power 0.00–655.35 kW #.##
○
○
05-03 Motor Rated Speed (rpm) 0–65535 1710
○
○ ○
05-04 Number of Motor Poles 2–48 4
○
○ ○ ○
05-05 Motor No-load Current 0–Pr.05-01 <default> #.##
○
○ ○
05-06 Motor Rs
0.000–65.535 Ω
0.000
○
○
05-07 Motor Rr
0.000–65.535 Ω
0.000
○
○
05-08 Motor Lm 0.0–6553.5 mH 0.0
○
○
05-09 Motor Lx 0.0–6553.5 mH 0.0
○
○

05-10
Torque Compensation
Low Pass Filter Time
0.001–10.000 sec. 0.020
○

05-11
Slip Compensation Low
Pass Filter Time
0.001–10.000 sec. 0.100
○

05-12
Torque Compensation
Gain
0–10 0
○
○

05-13 Slip Compensation Gain 0.00–10.00 1.00
○

05-14 Slip Deviation Level 0–1000% (0: disable) 0
○
○ ○

05-15
Slip Deviation Detection
Time
0.0–10.0 sec. 1.0
○
○ ○

05-16 Over-slip Action
0: Warn and keep operation
1: Fault and ramp to stop
2: Fault and coast to stop
0
○
○ ○

05-17 Hunting Gain 0–10000 (0: disable) 2000
○
○ ○
05-18
Accumulated Motor
Operation Time (Min.)
0–1439 0
○
○ ○ ○ ○
05-19
Accumulated Motor
Operation Time (day)
0–65535 0
○
○ ○ ○ ○

05-20 Core Loss Compensation 0–250% 10
○
05-21
Accumulated Motor
Power-on Time (Min.)
0–1439 0
○
○ ○ ○ ○
05-22
Accumulated Motor
Power-on Time (day)
0–65535 0
○
○ ○ ○ ○

05-23
Slip Compensation Gain
% (Power Generation
Mode)
0.0–100.0% 0.0
○
○

05-24
Slip Compensation Gain
% (Electricity Mode)
0.0–100.0% 0.0
○
○
