Delta VFD-ED Series

Chapter 11 Summary of Parameter Settings | VFD-ED
11-19
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
2: Over-torque detection during constant
speed operation, stop operating after
detection
3: Over-torque detection during
operation, continue to operate after
detection
4: Over-torque detection during
operation, stop operating after
detection
 06-09
Over-torque Detection
Level (OT2)
10–250% (rated current of the motor
drive)
150 ○ ○ ○ ○ ○
 06-10
Over-torque Detection
Time (OT2)
0.1–60.0 sec. 0.1 ○ ○ ○ ○ ○
 06-11 Current Limit
0–250% (rated current of the motor
drive)
200 ○ ○
06-12 Electronic Thermal Relay
0: Standard motor
1: Inverter motor
2: Disabled
2 ○ ○ ○ ○ ○
 06-13
Electronic Thermal
Characteristic
30.0–600.0 sec. 60.0 ○ ○ ○ ○ ○
 06-14
IGBT Overheat Warning
(oH1)
0.0–110.0°C 90.0 ○ ○ ○ ○ ○
 06-15
Stall Prevention Limit
Level
0–100% (refer to Pr.06-02, Pr.06-03) 50 ○ ○ ○
06-16
Present Fault Record
0: No fault
0
○
○
○
○
○
06-17
Second Most Recent
Fault Record
1: Over-current during acceleration (ocA) 0 ○ ○ ○ ○ ○
06-18
Third Most Recent Fault
Record
2: Over-current during deceleration (ocd) 0 ○ ○ ○ ○ ○
06-19
Fourth Most Recent Fault
Record
3: Over-current during constant speed
(ocn)
0 ○ ○ ○ ○ ○
06-20
Fifth Most Recent Fault
Record
4: Ground fault (GFF) 0 ○ ○ ○ ○ ○
06-21
Sixth Most Recent Fault
Record
5: IGBT short-circuit (occ)
6: Over-current at stop (ocS)
7: Over-voltage during acceleration (ovA)
8: Over-voltage during deceleration (ovd)
9: Over-voltage during constant speed
(ovn)
10: Over-voltage at stop (ovS)
11: Low voltage during acceleration
(LvA)
12: Low voltage during deceleration
(Lvd)
13: Low voltage during constant speed
(Lvn)
0 ○ ○ ○ ○ ○
