Delta VFD-ED Series

Chapter 11 Summary of Parameter Settings | VFD-ED
11-21
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
terminals (EF1)
51: Reserved
52: Password error after three attempts
(Pcod)
53: Reserved
54: Illegal communication command
(cE01)
55: Illegal communication address
(cE02)
56: Communication data length error
(cE03)
57: Communication attempts to write to a
read-only address (cE04)
58: Modbus transmission time-out (cE10)
59: Keypad transmission time-out (cP10)
60: Brake transistor error (BF)
61–63: Reserved
64: Mechanical brake feedback error
(MBF)
65: PG hardware error (PG5)
66: Magnetic contactor error (MCF)
67: Output phase loss (MPHL)
68: CAN BUS disconnected (CANF)
69–71: Reserved
72: Safe torque loss (STL1)
73: PG cd hardware error (PGcd)
74: PG absolute signal error (PGHL)
75: PG Z phase signal loss (PGAF)
76: Safe torque output stops (STO)
77: Safe torque loss 2 (STL2)
78: Safe torque loss 3 (STL3)
82: U-phase output phase loss (OPHL)
83: V-phase output phase loss (OPHL)
84: W-phase output phase loss (OPHL)
86: Leveling switch short-circuited (LSS)
87: Leveling switch open-circuited (LSo)
94: BTTx Fail (btt)
95: BTTx Error (bttE)
 06-22 Fault Output Option 1
0–65535 (refer to bit table for fault code
in Chapter 12)
0 ○ ○ ○ ○ ○
 06-23 Fault Output Option 2
0–65535 (refer to bit table for fault code
in Chapter 12)
0 ○ ○ ○ ○ ○
 06-24 Fault Output Option 3
0–65535 (refer to bit table for fault code
in Chapter 12)
0 ○ ○ ○ ○ ○
 06-25 Fault Output Option 4
0–65535 (refer to bit table for fault code
in Chapter 12)
0 ○ ○ ○ ○ ○
