Delta VFD-ED Series User Manual

Chapter 11 Summary of Parameter Settings | VFD-ED
11-34
11 Advanced Parameters
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
11-00 System Control
Bit 0 = 0: No function
Bit 0 = 1: ASR auto-tuning; PDFF
enabled
Bit 7 = 0: No function
Bit 7 = 1: Zero speed position
control is enabled
Bit 9 = 0: Dynamic PG origin auto-
tuning with load (support
by PGHSD-1)
Bit 9 = 1: Static PG origin auto-
tuning with load by
enabling PGHSD-1
Bit 15 = 0: Detect the position of
magnetic pole again when
power is applied
Bit 15 = 1: Start from the magnetic
pole position of the
previous power failure
when power is applied
0 ○ ○

11-01
Elevator Speed
0.10–4.00 m/s
1.00
○
○

11-02
Traction Sheave Diameter
100–2000 mm
400
○
○

11-03
Gear Ratio
1.00–100.00
1.00
○
○
 11-04 Suspension Ratio
0 = 1:1
1 = 2:1
2 = 4:1
3 = 8:1
1 ○ ○

11-05
Mechanical Inertial Ratio
1–300%
40
○
○

11-06
Zero speed Bandwidth
1–40 Hz
10
○
○

11-07
Low speed Bandwidth
1–40 Hz
10
○
○

11-08
High speed Bandwidth
1–40 Hz
10
○
○

11-09
PDFF Gain Value
0–200%
30
○
○

11-10
Speed Feed Forward Gain
0–500
0
○
○

11-11
Notch Filter Depth
0–20 db
0
○
○

11-12
Notch Filter Frequency
0.00–200.00 Hz
0.00
○
○
 11-13
Keypad Display for Low
Pass Filter Time
0.001–65.535 sec. 0.500 ○ ○ ○ ○ ○
 11-14
Motor Current at
Acceleration
50–200% 150 ○

11-15
Carriage Acceleration
0.20–2.00 m/s
2
0.75
○
11-16
Reserved
11-17
Reserved
11-18
Reserved
 11-19
Zero Speed Parking
Bandwidth
1–40 Hz 10 ○ ○
