Delta VFD-ED Series User Manual

Chapter 11 Summary of Parameter Settings | VFD-ED
11-37
13 View User-defined Parameters
Pr.
Parameter Name
Parameter Group 12 Setting Values
Display Address
Pr.00-00–Pr.11-20
Default
VF
VFPG
SVC
FOCPG
FOCPM
13-00
Present Fault Record
0616
-
○
○
○
○
○
13-01
Motor Operation at Present Fault
Time (min.)
0632 - ○ ○ ○ ○ ○
13-02
Motor Operation at Present Fault
Time (day)
0633 - ○ ○ ○ ○ ○
13-03
Frequency Command at Present
Fault
0653 - ○ ○ ○ ○ ○
13-04
Output Frequency at Preset Fault
0654
-
○
○
○
○
○
13-05
Output Current at Present Fault
0655
-
○
○
○
○
○
13-06
Motor Frequency at Present Fault
0656
-
○
○
○
○
○
13-07
Output Voltage at Present Fault
0657
-
○
○
○
○
○
13-08
DC Bus Voltage at Present Fault
0658
-
○
○
○
○
○
13-09
Output Power at Present Fault
0659
-
○
○
○
○
○
13-10
Output Torque at Present Fault
0660
-
○
○
○
○
○
13-11
Power Module IGBT Temperature at
Present Fault
0661 - ○ ○ ○ ○ ○
13-12
Multi-function Terminal Input Status
at Present Fault
0662 - ○ ○ ○ ○ ○
13-13
Multi-function Terminal Output
Status at Present Fault
0663 - ○ ○ ○ ○ ○
13-14
Drive Status at Present Fault
0664
-
○ ○ ○ ○ ○
13-15
Second Most Recent Fault Record
0617
-
○
○
○
○
○
13-16
Motor Operation at Second Most
Recent Fault Time (min.)
0634 - ○ ○ ○ ○ ○
13-17
Motor Operation at Second Most
Recent Fault Time (day)
0635 - ○ ○ ○ ○ ○
13-18
Third Most Recent Fault Record
0618
-
○
○
○
○
○
13-19
Motor Operation at Third Most
Recent Fault Time (min.)
0636 - ○ ○ ○ ○ ○
13-20
Motor Operation at Third Most
Recent Fault Time (day)
0637 - ○ ○ ○ ○ ○
13-21
Fourth Most Recent Fault Record
0619
-
○
○
○
○
○
13-22
Motor Operation at Fourth Most
Recent Fault Time (min.)
0638 - ○ ○ ○ ○ ○
13-23
Motor Operation at Fourth Most
Recent Fault Time (day)
0639 - ○ ○ ○ ○ ○
13-24
Fifth Most Recent Fault Record
0620
-
○
○
○
○
○
13-25
Motor Operation at Fifth Most
Recent Fault Time (min.)
0640 - ○ ○ ○ ○ ○
13-26
Motor Operation at Fifth Most
Recent Fault Time (day)
0641 - ○ ○ ○ ○ ○
13-27
Sixth Most Recent Fault Record
0621
-
○
○
○
○
○
13-28
Motor Operation at Sixth Most
Recent Fault Time (min.)
0642 - ○ ○ ○ ○ ○
