12 Descriptions of Parameter Settings | VFD-ED
01 Basic Parameters
: You can set this parameter during operation
Maximum Output Frequency
Control Mode
VF VFPG SVC FOCPG FOCPM Default: 60.00/50.00
Settings 5.00–299.00 Hz
Determines the AC motor drive’s Maximum Output Frequency. All the AC motor drive frequency command
sources (analog inputs -10–10 V) are scaled to correspond to the output frequency range.
1st Output Frequency Setting (base frequency/ motor’s rated frequency)
Control Mode
VF VFPG SVC FOCPG FOCPM Default: 60.00/50.00
Settings 0.00–299.00 Hz
Set this parameter according to the rated frequency on the motor nameplate. If the motor is 60 Hz, set this
parameter to 60. If the motor is 50 Hz, set it to 50.
1st Output Voltage Setting (base voltage/ motor’s rated voltage)
Control Mode
VF VFPG SVC FOCPG FOCPM
Default: 220.0/440.0
Settings 230V models 0.1–255.0 V
460V models 0.1–510.0 V
Set this parameter according to the rated voltage on the motor nameplate. If the motor is 220 V, set this
parameter to 220.0. If the motor is 200 V, set this parameter to 200.0.
There are many motor types in the market and the power system for each country is also different. The
economical and convenient solution is to install an AC motor drive. Then there is no problem using the
motor with different voltage and frequency inputs, and the motor drive can improve the original motor
characteristics and useful life.
Second Output Frequency Setting
Control Mode
VF VFPG Default: 0.50
Settings 0.00–299.00 Hz
Second Output Voltage Setting
Control Mode
VF VFPG Default: 5.0/10.0
Settings 230V models 0.1–255.0 V
460V models 0.1–510.0 V
Third Output Frequency Setting
Control Mode
VF VFPG Default: 0.50
Settings 0.00–299.00 Hz
Third Output Voltage Setting
Control Mode
VF VFPG Default: 5.0/10.0
Settings 230V models 0.1–255.0 V
460V models 0.1–510.0 V
Fourth Output Frequency Setting
Control Mode
VF VFPG SVC FOCPG
Default: 0.00
Settings 0.00–299.00 Hz
