Delta VFD-ED Series User Manual

12 Descriptions of Parameter Settings | VFD-ED
12-01-3

Output Frequency Upper Limit
Control Mode VF VFPG SVC FOCPG FOCPM Default: 299.00
Settings 0.00–299.00 Hz

Output Frequency Lower Limit
Control Mode VF VFPG SVC FOCPG FOCPM Default: 0.00
Settings 0.00–299.00 Hz
 Use the upper/lower output frequency settings to limit the actual output frequency. If the frequency setting
is lower than the start-up frequency, it runs with zero speed. If the frequency setting is higher than the
upper limit, it runs with the upper limit frequency. If the output frequency lower limit is larger than output
frequency upper limit, this function is invalid.

Accel. Time 1
Control Mode VF VFPG SVC FOCPG FOCPM Default: 3.00
Settings 0.00–600.00 sec.

Decel. Time 1
Control Mode VF VFPG SVC FOCPG FOCPM Default: 2.00
Settings 0.00–600.00 sec.

Accel. Time 2
Control Mode VF VFPG SVC FOCPG FOCPM Default: 3.00
Settings 0.00–600.00 sec.

Decel. Time 2
Control Mode VF VFPG SVC FOCPG FOCPM Default: 2.00
Settings 0.00–600.00 sec.

Accel. Time 3
Control Mode VF VFPG SVC FOCPG FOCPM Default: 3.00
Settings 0.00–600.00 sec.

Decel. Time 3
Control Mode VF VFPG SVC FOCPG FOCPM Default: 2.00
Settings 0.00–600.00 sec.

Accel. Time 4
Control Mode VF VFPG SVC FOCPG FOCPM Default: 3.00
Settings 0.00–600.00 sec.

Decel. Time 4
Control Mode VF VFPG SVC FOCPG FOCPM Default: 2.00
Settings 0.00–600.00 sec.
 The Acceleration Time determines the time required for the AC motor drive to ramp from 0.00 Hz to the
Maximum Output Frequency (Pr.01-00). The Deceleration Time determines the time required for the AC
motor drive to decelerate from the Maximum Output Frequency (Pr.01-00) down to 0.00 Hz.
