Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-00-4
● At the meanwhile, if Pr. 00-04 is set to 17 or 20, it will display in hexadecimal “0001h” with
LED u page is ON in the keypad.
● The setting 17 is the ON / OFF status of digital output by Pr. 02-18 setting and the setting 20
is the corresponding CPU pin ON / OFF status of digital output.
● User can set 17 to monitor the digital output status and then set 20 to check if the wire is
normal.
4.
● Set value 25: when display value reaches 100.00 %, the drive will show “oL” as an overload
warning.
5.
●
Set value 38:
bit 0: The drive is running forward.
bit 1: The drive is running backward.
bit 2: The drive is ready.
bit 3: Errors occurred on the drive.
bit 4: The drive is running.
bit 5: Warnings occurred on the drive.
Coefficient Gain in Actual Output Frequency
Factory Setting: 1.00
Settings 0~160.00
This parameter is to set user defined unit coefficient gain. Set Pr. 00-04 = 31 to display the
calculation result on the screen (calculation = output frequency * Pr. 00-05).
Software Version
Factory Setting: #.#
Settings Read only
Parameter Protection Password Input
Factory Setting: 0
Settings
0～65535
Display 0~3 (the times of password attempts)
This parameter allows user to enter their password (which is set in Pr. 00-08) to unlock the
parameter protection and to make changes to the parameter.
To avoid future inconvenience, be sure to write down the set value after setting this parameter.
Pr. 00-07 and Pr. 00-08 are used to prevent personnel set other parameters mistakenly.
When the user forget the password, clear the setting by input 9999 and press ENTER key, then
input 9999 again and press ENTER within 10 seconds. After decoding, all the settings will return
to factory setting.
When setting the password, all the parameters are set to 0, except Pr. 00-08.
Parameter Protection Password Setting
Factory Setting: 0
Settings
0～65535
0: No password protection or password is entered correctly (Pr. 00-07)
1: Password has been set
