Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-00-10
bit 0~3: Control frequency F page, unit of user defined (Pr. 00-04 = d10, PID feedback value) and
the decimal point of Pr. 00-26 which supports up to 3 decimal points.
bit 4~15: Control frequency F page, unit of user defined (Pr. 00-04 = d10, PID feedback value)
and the displayed units of Pr. 00-26.
0
0
0 h
0
0:no decimal place
1:one
2:tw
3:three
decimal place
o decimal place
decimal place
0: Hz
1: rpm
2: %
3: kg
user defined decimal place
user defined unit
Must be converted to decimal when using the keypad to set parameters.
Example: If user defined unit is inWG and the third decimal point, according to the information
above, corresponding to inWG is 01Axh (x is the set decimal point), and
corresponding to the third decimal place is 0003h. Then inWG and the third decimal
point displayed in hexadecimal is 01A3h, converted to decimal is 01A3h = 419.
Set Pr. 00-25 = 419 to complete setting.
Max. User Defined Value
Factory Setting: 0
Settings 0: Disable
0~65535 (when Pr. 00-25 set to no decimal place)
0.0~6553.5 (when Pr. 00-25 set to 1 decimal place)
0.00~655.35 (when Pr. 00-25 set to 2 decimal place)
0.000~65.535 (when Pr. 00-25 set to 3 decimal place)
When Pr. 00-26 is NOT set to 0, the user defined value is enabled. After selecting displayed unit
and decimal point by Pr. 00-25, the setting value of Pr. 00-26 will correspond to Pr. 01-00 (Max.
operation frequency of motor), then the operation frequency of motor will be a linear
correspondence with displayed value of digital keypad.
Example: When the frequency at Pr. 01-00 = 60.00 Hz, the max. user defined value at Pr. 00-26
is 100.0 %. That also means Pr. 00-25 is set at 0021h to select % as the unit.
NOTE
The drive will display as Pr. 00-25 setting when Pr. 00-25 is properly set and Pr. 00-26 is not 0.
User Defined Value
Factory Setting: Read only
Settings Read only
Pr. 00-27 will display user defined value when Pr. 00-26 is not set to 0.
User defined value is valid only when Pr. 00-20 (source of frequency) is set to digital keypad or
RS-485 communication.
